Specifications
Prof. juice filling machine.
1.Fully automatic/high configuration
2.PLC control/food grade SS
3.factory price,good quality
BW-2500B type machine is fully automatic with top configuration. The entire machine is made of food-grade stainless steel. The surface is special processed, so the appearance is beautiful.
1. Work flow :
Put cardboard into carton holder (manually) → Bottom preforming → Bottom heating and sealing → Ultrasonic capping (Optional)→Filling → Top preforming → Top heating and sealing → Date printing → Finished product
The whole process is controlled by PLC, and only need one person to operate.
2. Suitable for filling:
Juice, fruit vinegar beverage, dairy product, corn beverage, tea beverage, etc
3. Technical parameter:
Capacity | 200-1000ml |
Output | 2000-2500 cartons/h |
Packing material | cardboard carton / aluminium foil carton |
Shelf life | 3 to 12 months |
Capping | With capping (Optional) |
Filling temperature | cold filling: 2-50°C / hot filling: 80-94 °C |
Overall power | 25KW (three phases of power electricity) |
Compressed air | Pressure: 1.0-1.4 Mpa | Flow rate: 1.4-2M3/min |
Cooling water | Flow volume: ≥40L/ min | Temperature: ≤30°C |
Size: (L*W*H) | 3.7m*1.6m*2.8m |
Net Weight | 3500kg |
Installation requirement | Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle. |
4. Function:
1. PLC control, only need one worker.
2. Apply Touch screen which shows the relevant information for operator, and makes the operation easy.
3. Automatically record the working status, and can be long-term saved.
4. Automatic lubrication.
5. Automatically failure alarm, diagnosing, and solution indicating.
6. The filling capacity can be adjusted at will.
7. The capping function is optional.
8. Can be installed with remote debugging system, which can solve problems for long distance customers.
9. CIP cleaning.
